国外倒是价格可以，国内价格要严格按照一美金兑换10元人民币的比例去搞的
Product Description:
ASUS Motherboard Products
Intel® Processor Socket 1155 Series
P8Z77 WS
Board for Workstation & PC Solutions
Mfg. Model Number:
ASUS P8Z77 WS, retail kit.
SATA cables, SLI bridges, & Q-connector
included.
GreenASUS, RoHS Compliant
Features & Benefits:
ASUS P8Z77 WS Board provides you the Best Graphics Performance You've Ever Experienced!
Based on extensive benchmarking, the Gen3 4-Way CrossFireX™ offered by the P8Z77 WS works up to 50% faster than standard Gen2 4-Way CorssFireX™, giving professional and power users more graphics performance on demand. Using PCI Express 3.0 x16 links, the four GPUs can reach their full potential, perfect for both intense gaming and commercial uses such as mechanical and architectural design, interior design, aeronautics, plus audio and video production.
• Best Graphics Performance with Gen3 four-Way CrossFireX™ and Geforce® SLI™
• Dual Server Class Intel® Gigabit LAN Lower CPU Utilization and Improve Throughput Quality
• Up to 60% Hybrid Graphics Boost and 3X Faster Video Conversion with LucidLogix Virtu MVP
• 3X Faster Performance with one-click ASUS SSD Caching
• Fan Xpert 2 - The Most Customizable Fan Controls
Specifications:
Form Factor
ATX compliant, 12" x 9.6" (30.5cm x 24.4cm).
Processor
Single socket of Intel® H2, LGA1155
.
Support Intel® 3rd & 2nd generation Core™ desktop processors:
- Support Quad-Core Core™ i7 processor series
- Support Quad-Core Core™ i5 processor series
- Support Dual-Core Core™ i3 processor series
Support Intel® 22nm & 32nm
processors
Support Intel® Turbo Boost Technology 2.0 depends on the CPU models
Memory
Four DDR3 240-pin Dual Inline Memory Module (DIMM) sockets
Dual channel memory architecture
Support up to 32GB of Non-ECC Un-buffered DDR3-1600/1333/1066 memory
depends on processor models
Support Intel® Extreme Memory Profile (XMP)
Core Logic
Intel® Z77 Express Chipset
ASUS Feature
ASUS SMART DIGI+, ASUS Hybrid Processor - TPU, ASUS EPU, ASUS Digital Power Design, ASUS Exclusive Features, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design.
ASUS WorkstationFeature
4x PCIe x16 slots
1x vertical USB 2.0 Quick Gate
ASUS SASsaby series Cards support
ASUS WS Diag. LED
ASUS WS 3-color LED
Expansion Slot
Four PCI-E 3.0/2.0 x16 slots
Two PCI-E 2.0 x1 slots
Multi-GPU Support
Supports NVIDIA® 4-Way SLI™ Technology
Support ATI® 4-Way CrossFireX™ Technology
Supports LucidLogix® Virtu™ MVP Technology
Storage Support
Southbridge Intel® Z77 Express Chipset:
- Support two SATA3 6.0GB/s ports(white color)
- Support four SATA2 3.0GB/s ports(blue color)
- Support SATA RAID 0, 1, 5, & 10 .
- Support Intel® Smart Response Technology, Intel® Rapid Start Technology, & Intel® Smart Connect Technology.
Marvell® PCIe 9128 SATA controller:
- Support two SATA3 6.0GB/s ports(navy blue)
- Support SATA RAID 0, & 1.
ASMedia® PCIe SATA controller:
- Support two eSATA 6Gb/s ports
(red color)
Networking
One Intel® 82574L PCIe Gigabit LAN Controller with RJ-45 port
Audio
Realtek ALC898 7.1 Channel High Definition Audio Codec, support Jack-detection, Multi-streaming, & Front Panel Jack-retasking.
Audio Feature:
- Absolute Pitch 192khz/24bit True BD Lossless Sound
- Blu-Ray Audio Layer Content Protection
- DTS Surround Sensation UltraPC
- DTS Connect
Support Optical S/PDIF out port at back I/O
Graphics
Integrated Graphics Processor
Maximum shared memory of 1748 MB
Multi-VGA output support: DVI ports
- Support DVI with max. resolution 1920 x 1200 @ 60 Hz
USB
ASMedia® USB 3.0 controller:
- 2x USB 3.0 ports
at back
Intel® Z77 Express Chipset:
- 4x USB 3.0 ports (2x ports on-board, 2x ports at back)
- 9x USB 2.0 ports (5x ports on-board, 4x ports at back)
Internal I/O Connector
1x USB 3.0 connector support additional 2 USB 3.0 ports
2x USB 2.0 connectors support additional 4 USB 2.0 ports
1x Vertical USB 2.0 port
4x SATA 6Gb/s connectors
4x SATA 3Gb/s connectors
1x CPU Fan connector (4 -pin)
4x Chassis Fan connectors (4 -pin)
1x Optional Fan connector (4 -pin)
1x S/PDIF out header
1x Front panel audio connector (AAFP)
1x System panel (Q-Connector)
1x MemOK! button
1x TPU switch
1x EPU switch
1x Power-on button
1x Reset button
1x Clear CMOS jumper
Back I/O Connector
1x PS/2 keyboard/mouse combo port
1x DVI-I port
1x eSATA 6Gb/s port
2x LAN (RJ45) ports
4x USB 3.0 ports
4x USB 2.0 ports
1x Optical S/PDIF out port
6x Audio jacks
1x USB BIOS Flashback Button
BIOS
64 Mb Flash ROM with AMI BIOS
Manageability
WfM 2.0, DMI 2.0, WOL by PME, PXE.
Power
1x 24-pin EATX Power connector
1x 8-pin ATX 12V Power connector
1x 4-pin EZ_PLUG Power connector
[ 本帖最后由 davidxtb 于 2012-4-5 22:36 编辑 ] |
-
|
